5/2 Double Pilot Operated Pneumatic Valve – 3/8″

Description



FEATURES & BENEFITS :

5/2 Double Pilot Operated Pneumatic Valve – 3/8″  ( 5 Port, 2 Position )
High flow-rate capacity, Compact size.
Sturdy aluminium housing body for rust free performance, Long life.
External pilot air supply from a compressed air medium.
High Quality Japanese “O” rings for smooth functioning & long life.
Single or manifold mounting option. Wide range of manifolds available..
Wide range of threaded port size ranges from G1/8″ ~ G1/2”



TECHNICAL SPECIFICATIONS :

Medium Filtered Compressed Air
No. of Port / Position 5 Port, 2 Position
Operating Type External Pilot Operated
Operating Pressure Range 0.8 ~ 10 bar
Max. Pressure Range 12 bar
Ambient Temp. -10 ~ +60 degree C
Body Material Aluminium Alloy
