SECO Nylon Tube ( Straight )

SKU: SNA Categories: ,
Description



FEATURES & BENEFITS :

  • Suitable for high temp. industrial applications.
  • Excellent durability, Easy to install.
  • Good chemical & mechanical properties.
  • Resistance to flexural fatigue and movement.
  • Corrosion & abrasion resistant.
  • Good vibration absorption quality.
  • Working temperature – upto 100° C
  • Max. temperature – upto 120° C
  • Working temperature range : -40 ~ 100° C
  • Melting Temperature  :   210° C
  • Working pressure range  :  Vacuum ~ 50 bar
  • Available colors – White/Black.  ( Other colors on request ) ( MOQ – 500 Mtrs. Each Size/Color )





TECHNICAL SPECIFICATIONS :

Compatible Fluids  :-  Compressed Air,  Industrial & Other Aggressive fluids.

Working Pressure Range  :-  Vacuum to 50 bar   ( upto  725 PSI )

Working Temperature Range  :   -40 to +100° C  ( -40  to  +212° F )

Materials   :-  100% Virgin Nylon Material ( PA-6 )

Available Tube OD Sizes  :-   4mm, 5mm, 6mm, 8mm, 10mm & 12mm
Available Colors  :- White & Black  ( Other colors on request )                                                ( MOQ – 500 Mtrs. Each Size/Color )



MODELS & SIZES AVAILABLE  :

 Part No. I.D. x O.D. ( mm ) Each Roll ( Mtr. )
SNA-0420 2 x 4 100 M
SNA-0530  3 x 5 100 M
SNA-0640  4 x 6 100 M
SNA-0860 6 x 8 100 M
SNA-1080 8 x 10 100 M
SNA-1210 10 x 12 100 M
SNA-1290  9 x 12 100 M

Other Specific Sizes also available on request.



Standard Colors – White & Black.

MOQ – 500 Mtrs. for Other Colors/Each Size.





APPLICATIONS  :

SECO Nylon ( PA-6 ) Tubes are highly suitable for Pneumatic controls, Compressed air applications, Automotives, Robotics, Fuel & oil transfer, Hydraulic lines, Automotive gasoline & High pressure lubricants etc.
