₹1,314.00 ₹1,097.00
SYMBOL
FEATURES & BENEFITS :
* Compact design for individual machine installations.
* Easy & accurate pressure setting.
* Press to lock regulating knob for locking at any set pressure.
* Every component is processed through stringent quality standards to produce high quality parts combined with exceptional performance.
TECHNICAL SPECIFICATIONS :
Part No. | MR – 02 |
Connection size | 1/4″ BSP |
Medium | Compressed air |
Max. Flow (l/min) | 1546 |
Ambient temp. | -10 ~ + 60 Degree Celcius |
Regulation Type | Piston |
Pressure range | 0.5 ~ 8.0 kg/cm2
(0.05 ~ 0.80 Mpa) |
Body material | Aluminium die – cast |
Attachments | Pressure Gauge, bracket, 4 screws & plug. |
Weight | 205 gms |
