FEATURES & BENEFITS :
* Modular design suitable for in-line or wall mounting installations.
* Removes water and foreign particles effectively from compressed air system.
* Quick release polycarbonate bowls facilitate easy installation & maintenance.
* High quality polycarbonate bowls are suitable for crucial environments.
* Standard 5 micron filter element ensures maximum water and particle removal.
* Press to lock regulating knob for locking at any set pressure.
* Oil spray in mist ensures good lubrication to machines & moving components.
* Easy visibility of lubricator sight feed dome facilitates desired oil flow adjustment.
* Every component is processed through stringent quality standards to produce high quality parts combined with exceptional performance.
Technical Specifications :
| Part No. | SFR+L – 04 |
| Connection size | 1/2″ BSP |
| Medium | Compressed air |
| Max. Flow (l/min) | 2600 |
| Ambient temp. | -10 ~ + 60 Degree Celcius |
| Filtration | Standard : 5 Micron, Optional : 40 Micron |
| Pressure range | 0.5 ~ 9.9 kg/cm2 (0.05 ~ 0.99 Mpa) |
| Body material | Aluminium die – cast |
| Bowl material | Polycorbonate |
| Filter bowl capacity | 105 cc, |
| Lubricator bowl capacity | 125 cc |
| Recommended lubricating oil | ISO – VG 32 |
| Drainage | Semi-automatic drain (Drains below 0.5 kg/cm2) |
| Attachments | Pressure Gauge, bracket, 4 screws & plug. |
| Weight | 1480 gms |
